Main ultraloader design and construction

8000 kg capacity body

This body capacity will depend on chassis type and overall gvw
Body is generally built on chassis from 7.5 tonnes to 10 tonnes
Hydraulically driven rack and demount system



Body will be designed and constructed to suit to specific chassis wheel-base
Overall width of body can be constructed up to 2550mm
Beacon arch and front nudge bar

This is mounted to front of body and enables installation of beacons, work lamps, stop/ tail/ indicator lights

Styled beacon flyer with radius corners
Mounting brackets for stop/tail/indicators
1 pair of work lamps
60” 4 rotator beacon light bar

All steel body

With fully welded steel treadplate flooring

Twin tilt body rams
Double acting hydraulic cylinders with 70mm bores
Stainless steel tool locker

1 x 48"x20"x20" locker with draw fitted to near side of chassis (where possible)
Fitted with lockable stainless steel handle

Body side capping

Stainless steel capping fitted to protect body paintwork and is finished with an anti-slip safety tape
Vehicle securing

12 deck mounted lashing tie down rings with full tongues
Set of 4 deluxe transporter tie down straps with soft restraining loops

90” winch bobbins

X8 bobbins
Enables side winching for the recovery and loading of badly damaged vehicles

Spectacle lift

2000 kg capacity ( if required )

Gold zinc coated spectacle lift head
Fitted with flip over head for easy stowage when not in use
Spec beam is powered in and out with a manual safety lock and hydraulic check valve
Twin double acting hydraulic cylinders with 70mm bores and stainless steel rods
1 pair of spectacle lift tie down ratchet straps
1 pair of wheel space reducing bars are fitted to enable the transport of vehicles with small diameter wheels
50mm tow ball


Vision alert 60" light bar
With 4 rotators
Illuminated centre
1 pair of flyer mounted work lamps and 1 pair of flyer mounted stop/tail/indicator lamps

Radio remote winch control
Tow ball & 7 pin plug
24/12v dropper fitted to 7 pin plug

Hydraulic system

Power take off hydraulic pump
Vehicle gearbox will be fitted with a hydraulic pump
Cab mounted pto air switch with handbrake interlock or cable operated on certain vehicles
Chassis mounted hydraulic tank with in-built cartridge filter

5 bank spool valve set up

Winch control with electro/air hydraulic control
Slide body on/off
Tip body up/down (inc. Auto tilt)
Spectacle lift up/down
Spec beam in/out manual safety lock
Fully enclosed stainless steel spool valve cover

10 000 lb hydraulic winch

Fully compliant to new en 14492-1 regulations
With radio remote and manual override lever

3560kg line pull- rated line pull of 34.9kn
Single stage planetary gearing, ideally suited to slidebed and spec lift applications
Short drum and long drum options -165mm or 248mm lengths
100mm diameter drum with deep flanges. Extends rope life and assists wrapping
Heavy duty roller guide assemblywith greaseways and large diameter rollers
Spring loaded clutch- easy to use
Braking system spring applied, hydraulic release disc brake providing 100% braking

5 bank spool valve set up

Winch control with electro/air hydraulic control
Power body on-off
Tip body up-down (including auto tilt)
Spec up / down
Spec in / out


Primed and painted in 2 pack
Under body wax-oiled
